Air Series Af120 Quiet Edition High Airf

120mm 1650 RPM 63.47 CFM Hydraulic 30 dBA Air Series AF120 Quiet Edition High Airflow 120mm Fan Product Description Air Series AF120 Quiet Edition High Airflow 120mm Fan High Airflow for Efficient Large-Volume Cooling Air Series AF case fans perform best in unrestricted spaces with at least 3 cm (1.2”) of clearance, and they’re ideal for mounting at the rear or top of your PC case as exhaust fans for your PC’s motherboard and CPU, graphics accelerators, and other components that fill the case with heat. They work equally well as unrestricted intake fans for areas like side panels or bottom intakes. For high restriction areas like hard drive cages or in other tight spaces where there’s less air volume, check out our Air Series SP models of high static pressure fans. Performance AF120 Performance Edition AF120 Quiet Edition Size 120mm x 25mm Operating Voltage 7V – 12V Performance at 12V Airflow 63.47 CFM 39.88 CFM Static Pressure 1.1 mm/H20 .5 mm/H20 Sound Level 30 dBA 21 dBA Speed 1650 RPM 1100 RPM Power Draw 0.13 A 0.08 A Contents and Specifications Package contents AF120 Quiet Edition Fan Three colored rings in red, blue, and white Mounting Screws Voltage step-down adapter for lower speed operation System requirements Motherboard with an open standard 3-pin fan connector Model Brand Corsair Series Air Series AF120 Performance Edition Model CO-9050001-WW Details Type Case Fan Compatibility Case Fan Size 120mm Bearing Type Hydraulic RPM 1650 RPM Air Flow 63.47 CFM Noise Level 30 dBA Color Black Blades Features Features Static Pressure (mm/H2O): 1.1 mm/H2OPower Draw (@ +12V): 0.13AThe AF120 Performance Edition is a great choice for a high performance side panel intake or case exhaust, or even a ‘pull’ fan for a radiator or heatsink.Nine ultra-thin blades for excellent airflow at very low noise levels.Custom fan enclosure for ducting air in the right direction with minimal interference.Advanced Hydraulic Bearing for reliable, quiet operation. Rubberized corners for sound damping when installed with standard screws. User-replaceable colored rings so you can match your fans to your case Included voltage step-down adapter for even quieter operation. Dimensions & Weight Dimensions 120mm x 25mm Package Contents Package Contents AF120 Performance Edition Airflow Fan Three colored rings in red, blue, and white Voltage step-down adapter for lower speed operation Mounting Screws
