Asus Rampage V Extreme/u3.1 Lga 2011-v3

Product Description ASUS RAMPAGE V EXTREME/U3.1 LGA 2011-v3 Intel X99 ATX Motherboard Take X99 to the extreme Intel® Core™ i7 processors on LGA 2011-v3 socket Intel X99 Express chipset OC Socket, OC Panel, Safe Boot and ReTry buttons – Powerful tuning kit for breaking records Extreme Engine Digi+ IV – Primo components for rock-steady power DirectCU, X-Socket II, multiple thermal sensors and Fan Xpert 3 – Stay even cooler PCI Express 3.0 x4 M.2, dual SATA Express, 3T3R 802.11ac Wi-Fi – Unparalleled connectivity with blistering-fast transfer speeds SupremeFX 2014, Sonic Radar II, Intel Ethernet, LANGuard, GameFirst III, KeyBot, RAMDisk – Hear more, banish lag, accelerate loading and control ASUS RAMPAGE V EXTREME/U3.1 LGA 2011-v3 Intel X99 CPU Intel® Socket 2011-v3 Core™ i7 Processors Supports Intel® 22 nm CPU Supports Intel® Turbo Boost Technology 2.0 * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types. * Refer to www.asus.com for CPU support list ASUS RAMPAGE V EXTREME/U3.1 LGA 2011-v3 Intel X99 Chipset Intel® X99 Memory 8 x DIMM, Max. 64GB, DDR4 3300(O.C.)/3000(O.C.)/2800(O.C.)/2666(O.C.)/2400(O.C.)/2133 MHz Non-ECC, Un-buffered Memory Quad Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP) * Hyper DIMM support is subject to the physical characteristics of individual CPUs. * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). Multi-GPU Support Supports NVIDIA® 4-Way SLI™ Technology *1 Supports NVIDIA® 3-Way SLI™ Technology Supports NVIDIA® SLI™ Technology Supports AMD 4-Way CrossFireX Technology Supports AMD 3-Way CrossFireX™ Technology Supports AMD CrossFireX™ Technology ASUS RAMPAGE V EXTREME/U3.1 LGA 2011-v3 Intel X99 Expansion Slots 4 x PCIe 3.0/2.0 x16 (x16, x16/x16, x16/x8/x8 or x16/x8/x8/x8 mode with 40-LANE CPU; x16, x16/x8, x8/x8/x8 mode with 28-LANE CPU) *2 1 x PCIe 2.0 x16 (x4 mode) *3 1 x PCIe 2.0 x1 *3 Storage New Intel® Core™ i7 Processors : 1 x M.2 Socket 3, gray, , with M Key, type 2260/2280/22110 storage devices support ( Supports PCIE SSDs only) Intel® X99 chipset : 1 x SATA Express port, red, compatible with 2 x SATA 6.0 Gb/s ports 8 x SATA 6Gb/s port(s), red, *4, with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE mode) Support Raid 0, 1, 5, 10 Supports Intel® Smart Response Technology, Intel® Rapid Recovery Technology*5 ASMedia® SATA Express controller : *6 1 x SATA Express port, red, compatible with 2 x SATA 6.0 Gb/s ports ASUS RAMPAGE V EXTREME/U3.1 LGA 2011-v3 Intel X99 LAN Intel® I218V, 1 x Gigabit LAN Controller(s), featuring GAMEFIRST III Intel® LAN- Dual interconnect between the Integrated LAN controller and Physical Layer (PHY) Anti-surge LANGuard Wireless Data Network Wi-Fi 802.11a/b/g/n/ac Supports dual band frequency 2.4/5 GHz Up to 1300Mbps transfer speed ASUS RAMPAGE V EXTREME/U3.1 LGA 2011-v3 Intel X99 Bluetooth Bluetooth V4.0 ASUS RAMPAGE V EXTREME/U3.1 LGA 2011-v3 Intel X99 Audio ROG SupremeFX 8-Channel High Definition Audio CODEC – Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking – SupremeFX Shielding Technology – ELNA® premium audio capacitors Audio Feature : – Blu-ray audio layer Content Protection – DTS Connect – Optical S/PDIF out port(s) at back panel – Sonic SoundStage – Sonic SenseAmp – Sonic Studio – Sonic Radar II ASUS RAMPAGE V EXTREME/U3.1 LGA 2011-v3 Intel X99 USB Ports Intel® X99 chipset : 4 x USB 3.0 port(s) (4 at mid-board) Intel® X99 chipset : *7 6 x USB 2.0 port(s) (2 at back panel, black, 4 at mid-board) ASMedia® USB 3.0 controller : *8 10 x USB 3.0 port(s) (10 at back panel, blue) ASUS RAMPAGE V EXTREME/U3.1 LGA 2011-v3 Intel X99 OC Panel 2.6 ” LCM display EXTREME/NORMAL mode switch EXTREME Mode for subzero OC benching:*9 – VGA Hotwire – Subzero Sense – Slow Mode – Pause Switch – VGA SMB header – ProbeIt – 4 x 4-pin extra fan connectors NORMAL Mode for in-chassis usage:*10 – CPU Level Up OC button – FanSpeed control button – LCM backlight on/off button I/O Ports: – POWER：1 x SATA power connector – ROG_EXT port：1 x 18-1 pin data connection port ASUS RAMPAGE V EXTREME/U3.1 LGA 2011-v3 Intel X99 ROG Exclusive Features DirectCU thermal design ROG Connect : – RC Diagram – RC Remote – RC Poster Extreme Engine Digi+ IV : – IR3555 PoweIRstage® – MicroFine Alloy Chokes – 10K Black Metallic Capacitors ROG Extreme OC kit : – ReTry button – Safe Boot button – Start button – Reset button – Slow Mode – LN2 Mode – PCIe x16 Lane Switch – Debug LED ProbeIt KeyBot – CPU Level Up – XMP – Direct Key UEFI BIOS features : – ROG BIOS Print – GPU.DIMM Post – Tweakers’ Paradise – ROG SSD Secure Erase – Graphic Card Information Preview ROG RAMDisk GameFirst III iROG Extreme Tweaker USB BIOS Flashback Overclocking Protection : – COP EX (Component Overheat Protection – EX) – Voltiminder LED II Special Features 5-Way Optimization by Dual Intelligent Processors 5 – 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ Power Control, Fan Xpert 3, and Turbo App Gamer’s Guardian: – ESD Guards on LAN, Audio, KBMS and USB3.0/2.0 ports – DRAM Overcurrent Protection – 10K Black Metallic Capacitors – Stainless Steel Back I/O ASUS Wi-Fi GO! – Wi-Fi GO! Function: Cloud GO!, Remote Desktop, Remote Keyboard & Mouse, File Transfer – Wi-Fi GO! & NFC Remote app for portable smartphone/tablet, supporting iOS 7 & Android 4.0 systems ASUS Exclusive Features : – MemOK! – AI Suite 3 – Ai Charger+ – USB Charger+ – USB 3.0 Boost – Disk Unlocker ASUS EZ DIY : – ASUS CrashFree BIOS 3 – ASUS EZ Flash 2 – Push Notice ASUS Q-Design : – ASUS Q-Shield – ASUS Q-Code – ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED) – ASUS Q-Slot – ASUS Q-DIMM – ASUS Q-Connector Overclocking Protection : – ASUS C.P.R.(CPU Parameter Recall) Media Streamer Turbo App Fan Xpert 3 Operating System Support Windows® 8.1 Windows® 8 Windows® 7 Back I/O Ports 1 x PS/2 keyboard/mouse combo port(s) 1 x LAN (RJ45) port(s) 10 x USB 3.0 (blue) 2 x USB 2.0 (one port can be switched to ROG Connect) 1 x Optical S/PDIF out 5 x Audio jack(s) 1 x Clear CMOS button(s) 1 x ROG Connect On/ Off switch(es) 1 x ASUS Wi-Fi GO! module (Wi-Fi 802.11 a/b/g/n/ac and Bluetooth v4.0 Internal I/O Ports 2 x USB 3.0 connector(s) support(s) additional 4 USB 3.0 port(s) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 2 x SATA Express connector: red, with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE mode) 1 x M.2 Socket 3 for M Key, type 2260/2280/22110 storage devices support ( Support PCIE SSD only) 1 x TPM header 8 x SATA 6Gb/s connector(s) 1 x CPU Fan connector(s) (1 x 4 -pin) 1 x CPU OPT Fan connector(s) (1 x 4 -pin) 6 x Chassis Fan connector(s) (6 x 4 -pin) 1 x Thunderbolt header(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin ATX 12V Power connector(s) 1 x 4-pin ATX 12V Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x System panel(s) (Q-Connector) 1 x MemOK! button(s) 1 x Slow Mode switch(es) 9 x ProbeIt Measurement Points 3 x Thermal sensor connector(s) 1 x EZ Plug connector(s) (4-pin Molex power connector) 1 x Power-on button(s) 1 x Reset button(s) 1 x BIOS Switch button(s) 1 x LN2 Mode jumper(s) 1 x ROG extension (ROG_EXT) header(s) 1 x KeyBot Button 1 x Sonic SoundStage Button 1 x Safe Boot button 1 x ReTry button ASUS RAMPAGE V EXTREME/U3.1 LGA 2011-v3 Intel X99 Accessories User’s manual I/O Shield 10 x SATA 6Gb/s cable(s) 1 x ASUS 3T3R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant) 1 x 3-Way SLI bridge(s) 1 x 4-Way SLI bridge(s) 1 x SLI bridge(s) 1 x CrossFire cable(s) 1 x Q-connector(s) (2 in 1) 3 x Thermal sensor cable pack(s) 1 x 12 in 1 ROG Cable Label(s) 1 x X-Socket 2 kit 1 x ROG Door Hanger(s) OC Panel Kit: – 1 x OC Panel(s) – 1 x OC Panel 5.25-inch bay metal case – 1 x OC Panel Cable(s) – 1 x OC Panel screw pack(s) BIOS 2 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.7, WfM2.0, SM BIOS 2.8, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note, Last Modified log, F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory information. Manageability WfM2.0, DMI2.7, WOL by PME, PXE Support Disc Drivers ROG GameFirst III ROG RAMDisk ROG CPU-Z ROG Mem TweakIt Kaspersky® Anti-Virus DAEMON Tools Pro Standard ASUS WebStorage HomeCloud ASUS Utilities Form Factor Extended ATX Form Factor 12 inch x 10.7 inch ( 30.5 cm x 27.2 cm ) Note 1. 28-LANE CPUs can only support up to 3-Way SLI™/ 3-Way CrossFireX™ 2. The PCIE_X8_4 slot shares bandwidth with M.2 x 4. 40-LANE CPU: The PCIeX8_4 slot can only be used in x4 mode or lower when used simultaneously with the M.2 connector. If x8 mode is used, the two connectors will be mutually exclusive. 28-LANE CPU: The PCIE_X8_4 slot will be disabled and the M.2 connector will always be enabled. 3. The PCIE_X4_1 (gray) slot shares bandwidth with the PCIE_X1_1 slot, USB3_E910 and SATAExpress_E1 connector. When the PCIE_X4_1 slot is occupied by an X1 or X2 device, the SATAEXPRESS_E1 will be disabled. When the PCIE_X4_1 slot is occupied by X4 device, the SATAEXPRESS_E1, USB3_E910 ports, and the PCIE_X1_1 slot will be disabled. 4. Due to chipset behavior, the SATA6G_78, SATA6G_910 ports do not support IRST including RAID configuration. 5. These functions will work depending on the CPU installed. 6. These SATA ports share bandwidth with the PCIE_X4_1 slot, and when the PCIE_X4_1 slot is ocuupied, the SATA ports will be disabled. These SATA ports are for data
