Msi Micro Atx Ddr3 1600 Lga 1150 Motherb

Product Description MSI Micro ATX DDR3 1600 LGA 1150 Motherboard H81M ECO Model Brand MSI Model H81M Eco Supported CPU CPU Socket Type LGA 1150 CPU Type Core i7 / i5 / i3 / Pentium / Celeron (LGA1150) Chipsets Chipset Intel H81 Memory Number of Memory Slots 2×240pin Memory Standard DDR3 1600/1333/1066 MHz Maximum Memory Supported 16GB Channel Supported Dual Channel Expansion Slots PCI Express 3.0 x16 1 x PCI Express 3.0 x16 PCI Express x1 2 x PCI Express x1 PCI Slots 1 x PCI Slot Storage Devices SATA 3Gb/s 2 x SATA 3Gb/s SATA 6Gb/s 2 x SATA 6Gb/s Onboard Audio Audio Chipset Realtek ALC887 Audio Channels 8 Channels Onboard LAN LAN Chipset Intel i218-V Max LAN Speed 10/100/1000Mbps Rear Panel Ports PS/2 2 Video Ports D-Sub + DVI HDMI 1 x HDMI USB 3.0 2 x USB 3.0 USB 1.1/2.0 4 x USB 2.0 Audio Ports 3 Ports Internal I/O Connectors Other Connectors 1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 1 x 4-pin CPU fan connector 1 x 4-pin system fan connector 1 x 3-pin system fan connector 1 x Clear CMOS jumper 1 x Chassis Intrusion connector 1 x Front panel audio connector 1 x Parallel port connector 2 x System panel connectors 1 x Serial port connector 1 x TPM module connector Physical Spec Form Factor Micro ATX Dimensions (W x L) 9.6″ x 8.8″ Power Pin 24 Pin Features Features Supports 4th Gen Intel Core / Pentium / Celeron processors for LGA 1150 socketSupports DDR3-1600 MemoryUSB 3.0 + SATA 6Gb/s ECO Tech Design: Industry leading HW/SW design to optimize power ECO Center Pro: Friendly GUI, simple to operate with three mode ECO Performance: 100% performance, 24/7 stable and green Guard-Pro: Improved Protection and Power Efficiency Military Class 4: Top Quality & Stability Click BIOS 4: Easily Fine-tune Your System 4K UHD Support: Ultra-high Definition Visual Experience Intel Gigabit LAN: Always connected with Intel Gigabit LAN networking Fast Boot: Quickly Boot Up & Enter OS in A Few Seconds M-Flash: Simply Update & Backup Your BIOS Live Update 6: Easily Update The Latest BIOS & Drivers
